MP Filtri Bellhousing Damping Ring
$263.20 $543.20Price range: $289.52$263.20 through $597.52$543.20 INC GSTEX GST
These Damping Rings are positioned between the bell housing motor flange and the lid of a hydraulic tank. They help to reduce the transmission of vibrations and emission of noise generated by the system. Damping Rings provide a perfect hydraulic seal due to their specific profile.
Available in 4 Different Sizes to suit Frame Size D80 – D180
| Part # | Series | Motor Flange | Noise Reduction |
|---|---|---|---|
| ANMA200 | D80-90 | B5 | Up to 5 db |
| ANMA250 | D100-110 | B5 | Up to 5 db |
| ANMA300 | D132 | B5 | Up to 5 db |
| ANMA350 | D160-180 | B5 | Up to 5 db |
WARNING – IMPROPER USE OR IMPROPER SELECTION OF THE PRODUCTS/EQUIPMENT OR SYSTEMS DESCRIBED CAN CAUSE PERSONAL INJURY, DEATH AND PROPERTY DAMAGE
| Weight | N/A |
|---|---|
| Size | ANMA200 – D80-90, ANMA250 – D100-110, ANMA300 – D132, ANMA350 – D160-180 |
Brand
MP Filtri
